HN1300/HN1600
Product Name: Laminated Film Slitting Machine
Model No : HN1300/HN1600
Working Size : 500mm To 3000 mm
Slitting Machine-Cutting Size : 50 Mm To Maximum
Core Size :
On Rewind – 3 Inch (Optional: 1 Inch, 1.5 Inch, 6 inch)
On Unwind – 3 ,6 Inch
Diameter :
On Rewind – 600 Mm (Optional: 800mm)
On Unwind – 800.Mm(Optional:1000mm)
Product-(Kgs) :
On Rewind – Max 250 Kg
On Unwind – 1000 Kg
Application/Usage : Roll To Roll Slitting Of Tarpaulin And Any Type Of Film And Paper And Foil
M/C Weight : 1800 Kg To 2500 Kg Depended On Machine Web Width
M/C Dimension : L=3000 W=1500 H= 1100. To L= 5000 W=6500. H= 1400 Mm ( Dipanded On Machine Working Width )
M/C Speed : Max 500m/min
Power Consumption : 50 To 150 Unit Per Day Dipanded On Machine Working Width Hp 3 Phase
Electric Panel Option : Ac Drive With Auto Cut Off
Unwind Break Type : Magnetic Powder Break(Optional: Air Brake)
Rewind Clutch Type : Manual Or Auto
Cutting Blade Type : Rezor Blade/Shear Blade
Type : Duplex Slitter Rewinder



Our machines offer solutions for different industries, like paper bag making, paper cup raw board sheeting, carton box board cutting, food anti-oil paper cross-cutting, thermal paper roll making line, printing house and raw reel-material supplier searching.
