Fabric Rewinding Machine

Cutting material:Nylon, PP non-woven fabric, PET non-woven fabric
Max Slitting Width: 1600mm
Unwinding Dia.:600mm
Rewinding Dia.:300mm
Max Slitting Speed:120m/min
Send Inquiry
Chat Now
Description

We are a professional producer for woven fabric and non-woven fabric slitter for more than 12  years. We can do the slitter from 800-3500mm width, mini slitting width 10mm.

Polyester Satin

Nylon Taffeta
Polyester Taffeta
Acetate Taffeta
Poly Cotton

Basic Specification





1 SLITTING WIDTH 1620MM
2 UNWINDING DIAMETER 600MM(MAX)
3 UNWIDING CORE SHAFT AIR SHAFT
4 UNWIND CORE I.D. 25.4MM(1 INCH),40MM(1.5 INCH) or 76MM(3 INCH)
5 REWINDING DIA. 300MM(MAX)
6 REWINDING WIDTH MIN.10MM
7 REWINDING CORE SIZE 25.4MM(1 INCH),40MM(1.5 INCH) or 76MM(3 INCH)
8 BLADE TYPE COOL CIRCLE BLADE
9 MECHANICAL SPEED 120MIN/M
10 WORKING SPEED 30-80M/MIN
11 POWER SUPPLY 380V, 3 PHASES, 0.6Mpa
12 WELL THICKNESS: 10CM
13 METER COUNTER: HALL PROBE
14 WASTE EDGE UNIT: REWINDING
15 PNEUMATIC SOURCE 0.6 Mpa
16 MACHINE DIMENSION 2540MM*2500MM*1200MM
17 PACKING DIMENSION 2700MM*1250MM*1910MM
18 G.W. 1.4 TONS

Safe operation of slitting rewinding machine

1) Before operating the leveling machine, the staff should be familiar with the structure and performance of the equipment and how to operate it. They should operate according to the requirements in the manual.



2) When operating the leveling machine, the staff should wear labor protection articles and carry out proper personal protection.



3) First, push the sheet material to the leveling device through the feeder until the sheet material is clamped by the rollers.



4) When the equipment is running, it is strictly forbidden for workers to put their hands into the straightening roller to avoid accidents.



FEATURES:

1.Stand-alone tailstock , auto edge correction control system;
2.Auto Feeding system
3.Centre rewinding , Auto tension control for unwind and rewind
4.Scratch-proof treatment
5.Static-proof treatment
6.Optional Programble+ Human-computer interface
7.Auto length count
8.High precision , both side neat , clean and orderly after slitting
9.Min slit width up to 10mm (refer to materials and machine models)



FY1600C back look



FY800C front look








Guarantee and Policy

guarantee

Recommend Product:





We also provide color polyester satin ribbon as per your requirement:

image003.jpg image005(001).jpg

image007.jpg image009.jpg

image011(001).jpg image013(001).jpg



Heat Balde Cutting Machine for Satin Fabric

heating blade slitter
