HN1300RA Label Inspection Slitter Rewinders
Application:
REWINDING AND INSPECTING THE MATERIAL FROM 12-1500um PET,BOPP,CPP,LAMINATION MATERIAL OTHER PRINTED FILM AND FOIL.
Basic specification:
|
REWINDING WIDTH |
500mm-1330MM |
|
REWINDING THICKNESS |
12-2500UM |
|
UNWIND DIA |
MAX 1000MM |
|
UNWIND CORE I.D |
SHAFTLESS 3 INCH AND 6 INCH |
|
REWINDING DIA |
MAX 800MM |
| REWINDING CORE I.D |
SHAFTLESS 3 INCH AND 6 INCH |
|
MECHANICAL SPEED |
MAX350M/MIN |
|
WORKING SPEE |
MAX300M/MIN |
|
MACHINE FRAME THICKNESS |
50MM |
|
METER COUNTER |
METER COUNTER |
|
POWER SOURCE |
380V±10%,3 PHASE 4 WIRES,50Hz |
|
PNEUMATIC SOURCE |
MINI 0.6MPA |
| N.W/G.W (REF. ONLY): |
4500/4800 KG |
PART B: PRINTING INSPECTION SYSTEM SPECIFICATION
1 INSPECTION WIDTH: 300MM-1500MM
2 INSPECTION SPEED: 300M/MIN
3 INSPECTION ACCURACY: 0.10MM² (CONTRAST ≥ 20)
4 MINI THREADINESS SIZE: 0.10MM × 5MM(CONTRAST ≥ 20)
5 MINI PRINTING REGISTRATION DEVIATION: ±0.10MM
DETAILS PICTURE
