Slitter Rewinder Used
Slitter Rewinder Used APPLICATION
HN1600P is for slitting large rolling materials, such as PET, BOPP, PE, paper sticker, paper, compound printing paper and so on. Paper slitting thickness from 50-450gram.
Slitter Rewinder Used Basic specification
| 1 | SLITTING WIDTH | MAX1600MM |
| 2 |
SLITTING THICKNESS |
50-450 gram Paper |
| 3 |
UNWIND DIA |
MAX1400MM |
| 4 |
UNWIND CORE I.D |
3 INCH AND 6 INCH OPTIONAL: SHAFTLESS |
| 5 |
REWINDING DIA |
MAX1000MM |
| 6 |
REWINDING WIDTH |
MINI40MM |
| 7 |
REWINDING CORE I.D |
3 INCH OPTIONAL: 6 INCH |
| 8 |
SLITTING UNIT |
SHEAR BLADE |
| 9 |
MECHANICAL SPEED |
MAX400M/MIN |
| 10 |
WORKING SPEE |
MAX350M/MIN |
| 11 |
MACHINE FRAME THICKNESS |
40MM |
| 12 |
METER COUNTER |
METER COUNTER |
| 13 |
WASTE EDGE UNIT |
AIR BLOWER |
| 14 |
POWER SOURCE |
380V,3 PHASE,50Hz,21KW |
| 15 |
PNEUMATIC SOURCE |
0.6MPA |
| 16 |
N.W(REF. ONLY): |
3500 KGS |
| 17 |
MACHINE SIZE (REF. ONLY) |
3400MM*3100MM*1700MM |
| 18 | FLOOR SPACE(REF.ONLY) |
3500MM*3300MM |
| 19 | COLOR(REF. ONLY) |
WHITE AND YELLOW |
Slitter Rewinder Used FEATURES
A. BIG REWINDING DIA. MAX1000MM, MEET ALL YOUR REQUIREMENT;
B. VERY COST EFFECTIVE SLITTER
C. AUTOMATIC UP AND DOWN DISCHARGING THE FINISHED ROLL
D. MINI SLITTING WIDTH 40MM
E. FAST DELIVERY ONLY 40 DAYS
GUARANTEE AND SERVICE
1 ONE YEAR GURANTEE FOR THE KEY PARTS OF THE MACHINE, THE PARTS ARE AS FOLLOWING:
MOTOR, PLC, TOUCH SCREEN,MAGNETIC POWDER CLUTCH
2 MACHINE INSTALLING AND WORKER TRAINNING SERVICE.
A. ENGINEER AVAILABEL ON YOUR FACTORY TRAINNING AND INSTALLING
IF YOU PAY THE VISA COST, AIR TICKET, FOOD, HOTEL AND SUBSIDY.
B. TRAINNING YOUR WORKER AT OUR FACTORY SERVICE IS AVAILABEL
YOU ONLY NEED TO PAY THE HOTEL COST.
3 WHOLE LIFE TECHNICAL SUPPORT.
ABOUT HAVESINO ：
HAVESINO, as a professional paper reel cutting machine manufacturer, supply paper roll cutting machine and paper slitting machines, which are widely used in cutting corrugated roll paper, wormed roll paper, soaked roll paper with different width, speed and efficiency. On-site roll paper processing service is also provided as long as you demand. You're alwalys welcome to visit our factory!
