FABRIC SLITTING MACHINE
FY1600JC HEATING BLADE AND COOL BLADE SLITTER
SPECIFICATION
|
1 |
SLITTING WIDTH |
1620MM |
|
2 |
UNWINDING DIAMETER |
600MM(MAX) |
|
3 |
UNWIND CORE SHAFT |
AIR SHAFT |
|
4 |
UNWINDING CORE SIZE |
25.4MM(1 INCH),40MM(1.5 INCH) or 76MM(3 INCH) |
|
5 |
UINWINDING CORE QTY |
1PC |
|
6 |
REWINDING WIDTH |
MIN.10MM FOR HEAT BLADE |
|
MIN.20MM FOR COLD BLADE |
||
|
7 |
REWINDING DIA. |
300MM(MAX.) |
|
8 |
REWINDING CORE SIZE |
25.4MM(1 INCH),40MM(1.5 INCH) or 76MM(3 INCH) |
|
9 |
REWINDING CORE TYPE |
AIR SHAFT |
|
10 |
REWINDING CORE QTY |
2 PCS |
|
11 |
BLADE TYPE |
HEATING STRAIGHT BLADE |
|
12 |
BLADE QTY |
40PCS |
|
13 |
MECHANICAL SPEED |
120M/MIN |
|
14 |
WORKING SPEED |
30-80M/MIN |
|
15 |
POWER SUPPLY |
380V, 3 PHASES, 0.6Mpa |
|
16 |
MACHINE DIMENSION |
2540MM*1900MM*1200MM |
|
17 |
PACKING DIMENSION |
2700MM*750MM*1910MM |
|
18 |
G.W. |
1.4 TONS
|
MATERIAL of SLITTING
FY1600JC Fabric Slitting Machine, with both hot blade and cold blade, can slit both woven and non-woven fabric material, like Polyester Satin,Nylon Taffeta,Care Label,Garment Label,Clothing Label,Polyester Fabric,Micro Fiber, and other kinds of fabric material.
FEATURES OF FY1600JC FABRIC SLITTING MACHINE
A. With both heating and cold blade;
B. Max slitting width 1620mm, could slit most size of jumbo roll on the market;
C. Mini slitting width 10mm;
D. Very perfect of slitting edge;
E. Easy operation and installing, no need extra cost for learning installing and operation;
F. Easy maintance, only simple lubricate;
G.Long life using;
